Telehandlers
Telehandlers
Engine
Perkins EPA
Bucket Capacity
Power
74.4 kW / 2,400 r
Maximum Unloading Height
Maximum Digging Depth
Track Length
Track Width
-
Travel Speed
30 km/h
Gradeability
30°
Lifting Height
17.60 m / 57.74 ft
Max Capacity
4,000 kg / 8,819 lbs
Max Outreach
13.10 m / 42.98 ft
Lift Capacity at Max. Height
2,500 kg / 5,512 lbs
Lift Capacity at Max. Reach
700 kg / 1,543 lbs
Overall Length to Carriage
6.16 m / 20.21 ft
Tilt Angle
±9°
Weight
12,500 kg / 27,558 lbs
Leveling Width
-
Paving Mode
-
Exciting Force
-
Telescopic Arm
-
Backhoe Bucket Capacity
-
Rising Power
-
Bucket Digging Force
-
Maximum Traction
-
Dimension
6.16 × 2.42 × 2.70 m / 20.21 × 7.94 × 8.86 ft
Overall Length to Carriage
6.16 m / 20.21 ft
Overall Width
2.42 m / 7.94 ft
Overall Height
2.70 m / 8.86 ft
Weight
12,500 kg / 27,558 lbs
Overview
Get A Free Quote
Contact with our experts to get details
